2360 Bay


rt178

Photos may show optional equipment.

2022

2360 Bay

w/ 250 XL Pro XS FourStroke DTS Mercury®
Boat, Motor, & Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
$81395
USD

The Bay Boat, Evolved

The Ranger® 2360 is designed for maximum confidence and comfort offshore, with stealth and a respectable draft for prowling the flats. At 23' 5" the 2360 carries a 300-horsepower rating and an expertly flared bow to smooth out rough seas. The angler-designed interior boasts a clutter-free layout and clever storage with plenty of room for stand-up fishing or tending to trolling lines. Conveniences are integrated from bow to stern from the rear fold-down jump seats, large center console that can comfortably house a portable toilet to the lower, easier-to-access front casting deck. Within the hull is a massive stringer system with solid, reinforced chines and a world of our signature foam flotation that deliver that famous one-piece feel, along with our patented, stronger-than-steel pultruded fiberglass material. The Ranger 2360 truly is the bay boat, evolved.

Key Features

  • Exceptionally well-appointed for fishing or cruising
  • Optional T-Top for versatility
  • Capable nearshore hull with bay-friendly draft
  • Huge built-in cooler
  • Flip-down rear seats
rt178
z17
z17

Specifications

Length 7.14 m 23' 5''
Hull Length 7.14 m 23' 5''
Beam 2.59 m 102''
Max. Recommended HP 300 HP
Engine Shaft Length 63.5 cm 25''
Inside Depth 48.26 cm 19''
Draft (Engine, Bait, Fuel, Accessories) 35.56 cm 14''
Fuel Capacity 306.59 L 81 gal.
Baitwell Capacity 151.4 L 40 gal.
Total Person, Motor, Gear 1224.7 kg 2700 lbs.
Approximate Boat Weight (Add 300lbs for T-Top) 1542.21 kg 3400 lbs.
Rod Box Length - Port 2.74 m 9'
Max. Person Capacity 10 persons
Trailer GVWR 3084.43 kg 6800 lbs.
Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate) 8.99 m 29' 6''
Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate) 8.38 m 27' 6''
Width On Trailer 2.59 m 102''
Height On Trailer (Add Approx 3' for T-Top) 2.54 m 8' 4''

Motor Options

AVAILABLE MOTOR PRICE VIEW PRICE W/ PREP & FREIGHT
Mercury®
250 XL FourStroke DTS Warm Fusion
$82785

USD
Select Dealer
250 XL Pro XS FourStroke DTS
$81395

USD
Select Dealer
300 XL FourStroke DTS Warm Fusion
$84185

USD
Select Dealer
300 XL Pro XS FourStroke DTS
$84185

USD
Select Dealer
Mercury® Verado®
250 XL
$82180

USD
Select Dealer
250 XL Warm Fusion
$83585

USD
Select Dealer
300 XL
$84140

USD
Select Dealer
300 XL Warm Fusion
$85580

USD
Select Dealer

Standard Features

Power/Performance
  • Master battery switch
  • Available w/ a wide range of precision matched outboards
  • Binnacle throttle control
  • High performance stainless steel prop
  • Pultruded fiberglass transom
  • Fiberglass stringer system
  • Stainless steel steering wheel w/ knob assist
  • Hydraulic steering (may vary with engine model and setback plate)
  • Recirculating aerated livewell/baitwell leaning post combination w/ high speed pickup, dual pumps & in-line filter, rear
  • 14" hydraulic setback plate
Trailer Features
  • Swing-away tongue
  • Aluminum Wheels w/matching spare tire & wheel
  • Center swing jack
  • Fenders (Stainless steel)
  • Hydraulic surge disc brakes
  • LED lighting
  • Ranger Trail® vault hub lubrication system
  • Torsion axles
  • NMMA®/NATM certified
Electronics
  • Digital speedometer, Tach, Fuel, Trim & Water Pressure by engine manufacturer
  • Heavy duty 6 ga. TM wiring w/60 amp breakers
  • Corrosion resistant wiring w/ resettable breakers
  • 12V DC power receptacle
  • Console panel w/ stainless push-button switching w/ 30 amp breaker
  • LED cockpit, compartment & livewell light package
  • LED under water lights
Custom Details
  • Integrated rod storage
  • Deck mounted rod holders
  • Rod storage & port rod tubes
  • Storage under front & rear deck
  • Gelcoated storage boxes
  • Anchor locker w/ protective stainless steel plate for tie-off
  • Stainless steel compression lid locks
  • Stainless steel fittings
  • Stainless steel gas spring lid assist
  • Custom 240 quart fish box w/ large overboard drain
  • Gunnel & transom rod holders (8)
  • Leaning post rod holders (4)
  • Polished stainless steel pedestal base
  • Built-in 100 quart cooler
  • Trim tabs 12"x12"
  • Fresh water and raw water washdowns
Safety/Comfort
  • Fire extinguisher & horn
  • Automatic & manual bilge pump
  • Heavy duty rubrail w/ stainless steel insert
  • Skid-resistant deck & interior
  • Plexi windshield
  • Upright, level flotation
  • Custom-fitted premium marine upholstery: leaning post w/ 40 gal. baitwell & added storage
  • Folding rear bench seat w/ storage
  • Self-bailing cockpit w/ stainless steel scuppers
  • Stainless steel pull up tie cleats/ fore, aft, & midship
  • Baitwell/livewell shut off spray head
  • Swim platform w/ boarding ladder
  • Mirror on console cabin door

Options


Gallery

To view price with dealer prep and freight, use the search box to locate and choose a dealer near you.
